CAN & SERIAL INSTRUMENTATION - PROGRAMMABLE MODEL SELECTION

To select the appropriate can & serial instrumentation - programmable for your vehicle, please click on ADVANCED FILTERS.

X Advanced Filters Clear Filter

LCD Style

Housing

3100T / enGage® III

3100T / enGage® III

STEP CAD
Manual
View 360°
The Curtis enGage® III is a three function, microprocessor based instrument that can be factory or user defined to monitor various functions, including fuel, temperature, pressure, voltage, battery state of charge and maintenance/status. 2 versions: 12VDC, no buttons, no backlighting 12-48VDC, with buttons, with backlighting
LCD Style
Fixed Segment (Monochrome Only)
Housing
Rectangular
Display
TN LCD, Fixed Segment, monochrome
Serial
No
CANbus
CANopen, J1939
Analog In
0
Digital In
0
Outputs (MOSFET)
1 - 0.5 AMP
VCL
No
LEDs
8 (icons)
Push-Buttons
2 (optional)
Video-Input
No
Audible Alarm
false
Real-Time-Clock
No
Connector
AMP or Molex
Programmer Emulation
No
3140 / 3141

3140 / 3141

STEP CAD
Manual
View 360°
Curtis Models 3140/3141 are designed to display critical vehicle and motor controller data in an easy-to-read and attractive LCD. The display includes three 10 mm digits and six 5 mm digits and all digits are in 16-segment format to allow the full use of the alpha numeric character set. Models 3140/3141 integrate seamlessly with Model F2A and other Curtis CANopen-based motor controllers.
LCD Style
Fixed Segment (Monochrome Only)
Housing
Round
Display
TN LCD, Fixed Segment (16) Monochrome
Serial
No
CANbus
Yes
Analog In
0
Digital In
0
Outputs (MOSFET)
0
VCL
No
LEDs
Optional
Push-Buttons
0
Video-Input
No
Audible Alarm
No
Real-Time-Clock
No
Connector
AMP MATE-N-LOK
Programmer Emulation
No
3150 / enGage® NX1

3150 / enGage® NX1

Datasheet
STEP CAD
Manual
View 360°
The Curtis enGage NX1 is a bright color display packaged in a 52 mm gauge form factor. The LCD enables visualization of critical information and allows for a unique brand identity through a fully customizable user interface.
LCD Style
Dot Matrix / Color
Housing
Round
Display
1.54 in LCD, 240x240 pixel, color
Serial
Yes
CANbus
CANopen
Analog In
0
Digital In
3
Outputs (MOSFET)
1
VCL
No
LEDs
0
Push-Buttons
0
Video-Input
No
Audible Alarm
No
Real-Time-Clock
No
Connector
Tyco
Programmer Emulation
No
3750 / enGage® NX7

3750 / enGage® NX7

Datasheet
STEP CAD
View 360°
The Curtis enGage® NX VII (NX7) is a 7 inch, 1000 nit, touch screen display that utilizes a highperformance i.MX 8M+ processor, memory, and peripherals to enable innovative features such as digital video, machine learning, advanced graphical animations, and wireless connectivity. The NX7 is customizable in a multitude of ways, allowing OEMs to realize unique brand identity quickly. The display is equipped with CAN-FD, the latest CANbus technology, which provides faster data rates and increased reliability than CAN 2.0. Optional Bluetooth and WiFi enable communication to a mobile application or fleet telematics portal. Optional RFID enables vehicle security and operator identification through an
RFID tag or mobile phone.
LCD Style
Dot Matrix / Color
Housing
Rectangular
Display
7in. LCD, 1024x600, color
Serial
No
CANbus
2 CAN FD - CANopen, J1939
Analog In
4 Analog, 2 Frequency
Digital In
7
Outputs (MOSFET)
2- 2 AMP
VCL
No
LEDs
1
Push-Buttons
No
Video-Input
Yes
Audible Alarm
Yes - Speaker
Real-Time-Clock
Yes
Connector
Deutsch DTM
Programmer Emulation
No
3301T

3301T

Datasheet
STEP CAD
Manual
View 360°
The Curtis models 3301T and 3401T are powerful, easily configurable HMIs suitable for demanding, cost sensitive applications. The HMIs utilize high-bright color displays, allowing operators to clearly view diverse information in any lighting condition. The displays come equipped with easily adjustable, pre-set, user interfaces designed for various markets.
LCD Style
Dot Matrix / Color
Housing
Rectangular
Display
3.5
Serial
Yes
CANbus
CANopen, J1939
Analog In
0
Digital In
4
Outputs (MOSFET)
1 - 1.0 AMP
VCL
No
LEDs
0
Push-Buttons
10
Video-Input
No
Audible Alarm
Yes
Real-Time-Clock
Optional
Connector
AMP
Programmer Emulation
Yes
3401T

3401T

Datasheet
STEP CAD
Manual
View 360°
The Curtis models 3301T and 3401T are powerful, easily configurable HMIs suitable for demanding, cost sensitive applications. The HMIs utilize high-bright color displays, allowing operators to clearly view diverse information in any lighting condition. The displays come equipped with easily adjustable, pre-set, user interfaces designed for various markets.
LCD Style
Dot Matrix / Color
Housing
Rectangular
Display
4.3 in. LCD, WQVGA, color
Serial
Yes
CANbus
CANopen, J1939
Analog In
0
Digital In
4
Outputs (MOSFET)
1 - 1.0 AMP
VCL
No
LEDs
0
Push-Buttons
11
Video-Input
No
Audible Alarm
Optional
Real-Time-Clock
Optional
Connector
AMP
Programmer Emulation
Yes
3501

3501

STEP CAD
View 360°
The Curtis Model 3501 is a microprocessor based instrument panel that can be customized to monitor, display and control numerous vehicle functions in a single integrated package.
The panel is fully CANopen compatible.
LCD Style
Dot Matrix / Monochrome
Housing
Rectangular
Display
FSTN LCD, 240x128, Dot Matrix, Monochrome
Serial
Yes
CANbus
CANopen
Analog In
0
Digital In
4
Outputs (MOSFET)
1 - 1.0 AMP
VCL
No
LEDs
6
Push-Buttons
5
Video-Input
No
Audible Alarm
Optional
Real-Time-Clock
No
Connector
AMP
Programmer Emulation
Yes
840

840

STEP CAD
Manual
View 360°
Displays various system parameters, such as battery state-of-charge, operating hours or maintenance status from a Curtis motor controller or other serial communication source.
LCD Style
Dot Matrix / Monochrome
Housing
Round
Display
TN LCD, 8-character Dot Matrix, Monochrome
Serial
Yes
CANbus
Yes
Analog In
0
Digital In
0
Outputs (MOSFET)
2 PWM (optional)
VCL
No
LEDs
3 or 6
Push-Buttons
0
Video-Input
No
Audible Alarm
false
Real-Time-Clock
No
Connector
Molex
Programmer Emulation
No
enGage® VI

enGage® VI

STEP CAD
Manual
View 360°
The Curtis enGage® VI & VII display is a microprocessor based, programmable, CAN compatible instrument with full Input/Output capability.
LCD Style
Dot Matrix / Color
Housing
Rectangular
Display
3.5 in. LCD, QVGA, color
Serial
Yes
CANbus
CANopen, J1939
Analog In
2 Analog, 2 Frequency
Digital In
8
Outputs (MOSFET)
2 - 2.0 AMP
VCL
Yes
LEDs
0
Push-Buttons
5
Video-Input
Yes
Audible Alarm
Yes
Real-Time-Clock
Yes
Connector
Deutsch DTM
Programmer Emulation
Yes
enGage® VII

enGage® VII

STEP CAD
Manual
View 360°
The Curtis enGage® VI & VII display is a microprocessor based, programmable, CAN compatible instrument with full Input/Output capability.
LCD Style
Dot Matrix / Color
Housing
Rectangular
Display
5.7 in. LCD, QVGA, color
Serial
Yes
CANbus
CANopen, J1939
Analog In
5 Analog, 3 Frequency
Digital In
16
Outputs (MOSFET)
4 - 2.0 AMP
VCL
Yes
LEDs
0
Push-Buttons
5
Video-Input
Yes
Audible Alarm
Yes
Real-Time-Clock
Yes
Connector
Deutsch DTM
Programmer Emulation
Yes
